Model |
|
Image Device |
1/3" Sony & Sharp CCD sensor |
Scanning Frequency |
NTSC:15,734KHz(H), 60Hz(V);PAL: 15,625KHz(H),50Hz(V) |
Scanning System |
NTSC: 525 line 2:1 interlace PAL:625 lines 2:1 interlace |
Effective Pixels |
NTSC: 512(H) x 492(V); PAL:512(H) x 582(V) |
Electronic Shutter |
N:1/60- 1/100,000sec (Auto);P:1/50-1/100,000sec (Auto) |
Horizontal |
520/420 TV lines |
White-balance |
Auto white balance (2500°K~9500°k) |
Synchronizing System |
Internal |
Sensitivity |
0.2 Lux , 0 Lux at IR on / F2.0 |
BLC |
Auto |
Signal to Noise |
More than 48dB (AGC off) |
IR Distance |
25 Meters (Based on: object of view reflected IR light) |
IR LED |
High Light LED x 56 pcs |
IR View Angle |
View angle: 70°, Beam spread: 40°/per LED |
IR Wavelength |
850nm ± 25nm |
LED Life |
More than 10,000 hours |
Lens |
6 mm Standard (4,6,8,12mm option) |
Power Consumption |
IR on: 500mA, IR off: 80mA (DC 12V) ± 5mA |
Power Supply |
DC 12V |
Temperature |
Operating: -10 to 50°C |
Video Output |
Composite 1.0 Vp-p at 75 ohm |
Construction |
Aluminum with sunshield weatherproof |
Dimensions |
95(W) x 90(H) X 160(L) mm |
Weight |
0.450kg |
