Image Device |
1/3" Sony & Sharp CCD sensor |
Scanning Frequency |
NTSC: 15,734KHz(H), 60Hz(V); PAL: 15,625KHz(H),50Hz(V) |
Scanning System |
NTSC: 525 line 2:1 interlace PAL:625 lines 2:1 interlace |
Effective Pixels |
NTSC: 512(H) x 492(V); PAL:512(H) x 582(V) |
Electronic Shutter |
N:1/60- 1/100,000 sec (Auto); PAL:1/50-1/100,000sec (Auto) |
Horizontal |
520/420 TV Lines |
White-balance |
Auto white balance (2500°K~9500°K) |
Synchronizing System |
Internal |
Sensitivity |
0.1 Lux , 0 Lux at IR on / F2.0 |
BLC |
Auto |
Signal to Noise |
More than 48dB AGC off |
AGC |
Yes |
Gamma Correction |
0.45 |
IR Distance |
15 Meters (Max.) |
IR LED |
28 pcs LED |
IR Status |
Under 10 Lux by CDS auto control |
IR View Angle |
View angle: 70°, Beam spread: 40°/per LED |
IR Wavelength |
850nm ± 25nm |
LED Life |
More than 10,000 hours |
Lens |
6mm Standard |
Power Consumption |
IR on: 450mA, IR off: 120mA ± 5mA |
Power Supply |
12VDC |
Temperature |
Operating: -10 to 50°C |
Video Output |
Composite 1.0 Vp-p at 75 ohm |
Construction |
Aluminum with sunshield weatherproof |
Dimensions |
70(Ø) x 120(L) mm |
Weight |
400 g |
