▲GL-302
Model
GL-302 ; GL-302IP
Type
Outdoor/Indoor Pan/Tilt
IP can be used for IP Surveillance
Max. Load
7 kg
Material
Plastic Steel
PAN
355°
TILT
100°
Dimension
179(L)X115(W)X180(H)mm
Packing
12 pcs in one carton
N.W,G.W, Cu’ft
GL-302: 19 kg, 22 kg 2 cu’ft
GL-302IP: 25 kg, 26 kg, 2 cu’ft
Model No.:
GL-302IP
Description
IP PTZ Receiver
Feature:
l Built in PELCO D 2400 Protocol.
l PAN & TILT control.
l Lens control: zoom, focus.
l 1 Auxiliary Relay provide for any desired functions: alarm, wash/wipers, lighting
l Easy addressed code setting. (00-99).
l Allows the pan tilt power AC24V, zoom lens power DC12 (2A-Max.).
l Built-in power surge protection.
l Support all pan, tilt, zoom lens.
l Low Cost, economic type.
l Easy wiring.
l 33 Molex cable included for wire
connection with PTZ devices.
(2 pin, 4 pin, 8 pin).
Operating Voltage
AC 24V
Transmission
RS485
Cable
CAT 5 Twisted Pair Cable
Transmission Range
1200 meters
Storage Temperature
-30℃~70℃
Operation Temperature
-10℃~45℃
